Folding square

What it is

Folding square. Key specifications: dimensions (mm) 8x70.

A spindle is the square-section steel rod that connects the two handles through the lock and transmits the movement to the latch; it may be a split or expanding type to adapt to the thickness of the door.

What it is for

Used for assembly work.

How to use it

Choose a spindle with a section that matches the lock and a length suited to the thickness of the leaf; reducers adapt the spindle to smaller holes. Slip it into the lock and handles and secure it with grub screws or screws. Check that the handle has no play and returns to position by itself.

Where it is used

• Residential construction
• Building maintenance

Technical data

• Dimensions (mm): 8x70

Who it is for

Designed for metal fabricators and joiners.
