SDS-plus Extreme bit 5x310x250mm DeWalt DT9507-QZ

What it is

The DeWalt DT9507-QZ is an Extreme bit with an SDS-Plus shank, a diameter of 5 mm and a long working length of 250 mm, designed for deep, small-diameter holes in concrete. The carbide head and two-cutting-edge body ensure centred, clean holes even when great depths must be reached without deviation.

A masonry bit is a carbide-tipped bit for drilling concrete, brick and stone with a hammer drill or rotary hammer.

What it is for

Used for drilling reinforced concrete, in hammer or rotary hammer mode and for drilling solid and hollow masonry, clay brick and blocks.

How to use it

Choose the machine's shank type (straight, SDS-Plus or SDS-Max) and the diameter required by the wall plug. Start the hole at low speed, then engage hammer action, holding the bit square to the surface and without forcing, withdrawing it frequently to clear the dust. Clean the dust out of the hole before inserting the plug.

Where it is used

• Residential construction
• Building services
• Renovation

Technical data

• Diameter (mm): 5
• Head type: Carbide grit
• Height (cm): 39,4
• Working length (mm): 250
• Masonry drilling type: SDS
• Application material: Concrete
• Shank connection: SDS PLUS
• Pack: Label

Who it is for

Designed for electricians, plumbers, bricklayers and heating and plumbing engineers.

Related products

• SDS-plus Extreme bit 6.5x160x100mm DeWalt DT9520-QZ
• SDS-plus Extreme bit 5x210x150mm DeWalt DT9506-QZ
• Cordless drill driver XRP 18V 2x5.0Ah DeWalt DCD991P2-QW — from the category Hammer Drills, Drill Drivers and Rotary Hammers
• Percussion Anchor Spike 5 x 32, DeWalt DFM3110240 — from the category Heavy-Duty Anchors
• Cordless rotary hammer SDS-Plus XR lithium 18V 5.0Ah brushless dual chuck DCH274P2T-QW DeWalt — from the category Rotary Hammers
• Browse the whole category: Drill Bits for Granite, Masonry and Concrete

Before you order

In your request, please state the length, the diameter, the connection type and the quantities required, so we can give you the right quotation first time.

For prices and availability, request a quote from AMES Srl: we will reply with our quotation, delivery times and, where needed, an equivalent technical alternative.
